Cast Alloy

IN 625

IN 625 is solid-solution strengthened with excellent corrosion resistance and high-temperature stability. The combination of strength and corrosion resistance makes IN 625 particularly suitable for applications in the hot corrosion regime of gas turbine engines, along with chemical processing and marine applications due to its high chromium and molybdenum content. Qualified to AMS 5401 and multiple OEM specifications, IN 625 supports a wide range of structural and casing components.
Industry Specification
AMS 5401
Industries
Aerospace
Power Generation
Military & Defense
General Industrial
Space Exploration

Nominal Chemistry (wt %)

IN 625 is a weldable nickel-base superalloy used for conventionally cast structural components up to 980°C.
0.05
Carbon
0.2
Aluminium
Boron
21.5
Chromium
Cobalt
Hafnium
9
Molybdenum
3.6
Niobium / Columbium
Tantalum
0.2
Titanium
Tungsten
Zirconium
Iron
Bal
Nickel
